Product Features

Stable Power Output

Provides 48V nominal voltage, 100Ah nominal capacity and 4800Wh rated energy for residential energy storage and backup power systems.

Smart BMS Protection

Supports stable charging and discharging with 100A continuous discharge current, 200A peak discharge current and IP54 protection.

CAN / RS485 / RS232 Communication

Communication support helps integrate the battery with residential energy storage systems, inverters and monitoring equipment.

Long Cycle Life

Catalog cycle life is >4000 at 25°C, 0.5C and 100% DOD for long-term residential energy storage applications.

Technical Specifications

EF48100H-L Product Parameters

Main Parameters
ModelEF48100H-LNominal Voltage48V
Maximum Charge Voltage54VDischarge Cut-off Voltage40.5V
Nominal Capacity100AhRated Energy4800Wh
Electrical Performance
Maximum Charge Current100AMaximum Continuous Discharge Current100A
Maximum Peak Discharge Current (5S)200A
Temperature & Protection
Charge Temperature0~+55°CDischarge Temperature-20~+65°C
Communication PortCAN / RS485 / RS232IP Rating of EnclosureIP54
Protection LevelIP54Storage Temperature(℃)-20~+45°C
Physical & Installation
TerminalsM8Dimension482*550*156mm
Weight42kg
Lifecycle & Compliance
Cycle Life>4000

FAQ

What is the EF48100H-L and where is it used?

The EF48100H-L is intended for residential solar storage and backup-power systems. Its listed core specifications are 48V nominal voltage, 100Ah nominal capacity, 4800Wh rated energy. Final compatibility must be confirmed against the equipment voltage, load and mechanical space.

How should the EF48100H-L be charged?

Use a charger whose chemistry, voltage and current settings match the EF48100H-L. The listed charging limits are maximum charge voltage 54V, maximum charge current 100A. Charger profile, connector polarity and BMS settings should be verified before use.

What discharge performance does the EF48100H-L provide?

Discharge capability must be matched to the equipment's continuous and startup loads. The listed values are discharge cut-off voltage 40.5V, maximum continuous discharge current 100A, 5-second peak current 200A, cycle life >4000. Cable gauge, fusing and protection settings must be sized for the complete system.

What are the size, weight and temperature limits of the EF48100H-L?

For the EF48100H-L, the listed physical and environmental specifications are dimensions 482*550*156mm, weight 42kg, charge temperature 0~+55°C, discharge temperature -20~+65°C. Connector, wire and enclosure options can change final dimensions and weight.

Can the EF48100H-L be customized for an OEM project?

Hysincere can review the EF48100H-L for OEM/ODM integration, including connector, wire, enclosure, BMS and labeling requirements. Product-specific notes: listed communication: CAN / RS485 / RS232; protection level: IP54. Provide the device voltage, normal and peak current, installation space, operating temperature and required certifications for engineering confirmation.
