Product Features

LF12100-S-T50 12.8V 100Ah Bluetooth Power

Delivers 1280Wh rated energy for RV, marine, outdoor power and smart app monitoring applications.

Smart APP Battery Monitoring

Cellphone connected battery design supports convenient smart app monitoring for battery status and system operation.

Smart BMS Protection

Supports safer charge and discharge operation with intelligent battery management. Supports 200A continuous discharge and 350A peak discharge for demanding loads.

Starter Battery Output

Designed with special starter battery output support, including high-current performance for starting applications.

Hysincere Bluetooth Connection Series LiFePO4 battery application scenario with smart app monitoring

LF12100-S-T50 12.8V 100Ah LiFePO4 Battery for Starter Battery with Bluetooth Monitoring

The LF12100-S-T50 is a 12.8V 100Ah Starter LiFePO4 Battery from the Hysincere Bluetooth Connection Series, designed for starter battery applications requiring high cranking current and Bluetooth monitoring. It delivers 1280Wh rated energy with 200A / 1100CCA continuous discharge performance. It also supports Bluetooth smart app monitoring.

The LF12100-S-T50 is a 12.8V 100Ah Starter LiFePO4 Battery from the Hysincere Bluetooth Connection Series, designed for starter battery applications requiring high cranking current and Bluetooth monitoring. It delivers 1280Wh rated energy with 200A / 1100CCA continuous discharge performance. It also supports Bluetooth smart app monitoring.

Hysincere battery smart BMS protection technology for LiFePO4 and energy storage battery systems

LF12100-S-T50 Smart BMS Protection for 200A / 1100CCA Continuous Discharge

The LF12100-S-T50 is designed with smart BMS protection to support safer charge and discharge operation in starter battery applications requiring high cranking current and Bluetooth monitoring. It supports 200A / 1100CCA continuous discharge, 350A peak discharge, IP65 protection, charging from 0~+55°C and discharging from -20~+60°C. It supports 4S4P configuration for flexible system design.

The LF12100-S-T50 is designed with smart BMS protection to support safer charge and discharge operation in starter battery applications requiring high cranking current and Bluetooth monitoring. It supports 200A / 1100CCA continuous discharge, 350A peak discharge, IP65 protection, charging from 0~+55°C and discharging from -20~+60°C. It supports 4S4P configuration for flexible system design.

Hysincere deep cycle battery life technology visual for long-lasting rechargeable battery performance

LF12100-S-T50 ≥4500 Cycle Life Deep-Cycle LiFePO4 Battery

The LF12100-S-T50 is built for long service life with ≥4500 cycle life, supporting stable rechargeable battery performance for B2B power applications. With 1280Wh rated energy, 200A / 1100CCA continuous discharge and 5-year warranty support, it is suitable for reliable long-term use in starter battery applications requiring high cranking current and Bluetooth monitoring.

The LF12100-S-T50 is built for long service life with ≥4500 cycle life, supporting stable rechargeable battery performance for B2B power applications. With 1280Wh rated energy, 200A / 1100CCA continuous discharge and 5-year warranty support, it is suitable for reliable long-term use in starter battery applications requiring high cranking current and Bluetooth monitoring.

Technical Specifications

LF12100-S-T50 Product Parameters

Main Parameters
ModelLF12100-S-T50Nominal Voltage12.8V
Maximum Charge Voltage14.6VDischarge Cut-off Voltage12.4V
Nominal Capacity100AhRated Energy1280Wh
Electrical Performance
Maximum Charge Current200AMaximum Continuous Discharge Current200A / 1100CCA
Maximum Peak Discharge Current (5S)350AMaximum Series & Parallel4S4P
Temperature & Protection
Charge Temperature0~+55°CDischarge Temperature-20~+60°C
IP Rating of EnclosureIP65Protection LevelIP65
Physical & Installation
TerminalsStarter Terminal (S terminal)Dimension332*172*220mm
Weight11kg
Lifecycle & Compliance
Cycle Life≥4500LCD ScreenNO
Certification(EU) 2023/1542 CE MSDS UN38.3

FAQ

What applications is the LF12100-S-T50 battery suitable for?

The LF12100-S-T50 is suitable for 24V/36V energy systems and special starter applications. It is designed as a Bluetooth connection with smart app monitoring with 12.8V nominal voltage, 100Ah capacity and 1280Wh rated energy.

Does the LF12100-S-T50 support Bluetooth monitoring?

Yes. The LF12100-S-T50 belongs to the Bluetooth Connection Series and is designed for smart app monitoring, allowing users to check battery status more conveniently from a mobile device when the final system is configured correctly.

What are the charging and discharge specifications of the LF12100-S-T50?

The LF12100-S-T50 uses 12.8V nominal voltage, 14.6V maximum charge voltage and 12.4V discharge cut-off voltage. It supports 200A maximum charge current, 200A / 1100CCA maximum continuous discharge current and 350A maximum peak discharge current.

Can the LF12100-S-T50 be connected in series or parallel?

The catalog lists model-specific: 2S4P, 1S4P or 4S4P connection support for the LF12100-S-T50 or its series. For safe system design, series/parallel wiring, charging equipment, fusing and communication settings should be confirmed before installation.

What temperature range, cycle life and warranty does the LF12100-S-T50 provide?

The LF12100-S-T50 is specified for charging within 0~+55°C and discharging within -20~+60°C. The catalog cycle life is ≥4000, and the series is listed with 5 years warranty support. Actual service life depends on depth of discharge, load profile, charging method and operating environment.
