Product Features

LF2467N-BJ 25.6V 67Ah Self-Heating Power

Delivers 1715Wh rated energy for RV, marine and low-temperature energy storage applications.

Automatic Self-Heating Under 0°C

Supports automatic self-heating when charging under 0°C for dependable cold-weather battery operation.

Cold-Weather Charge Range

Supports charging from -20°C~+55°C and discharging from -20~+60°C for low-temperature outdoor use.

Smart BMS Protection

Supports safer charge and discharge operation with intelligent battery management. Supports 50A continuous discharge and 100A peak discharge for demanding loads.

Hysincere Self-heating Series battery application scenario for cold weather and low temperature energy storage

LF2467N-BJ 25.6V 67Ah LiFePO4 Battery for 24V Cold Weather RV and Marine Power

The LF2467N-BJ is a 25.6V 67Ah Self-Heating LiFePO4 Battery from the Hysincere Self-heating Series, designed for 24V cold-weather RV, marine and low-temperature energy storage applications. It delivers 1715Wh rated energy with 50A continuous discharge performance. It also supports automatically self-heating when charging under 0°C.

The LF2467N-BJ is a 25.6V 67Ah Self-Heating LiFePO4 Battery from the Hysincere Self-heating Series, designed for 24V cold-weather RV, marine and low-temperature energy storage applications. It delivers 1715Wh rated energy with 50A continuous discharge performance. It also supports automatically self-heating when charging under 0°C.

Hysincere battery smart BMS protection technology for LiFePO4 and energy storage battery systems

LF2467N-BJ Smart BMS Protection for 50A Continuous Discharge

The LF2467N-BJ is designed with smart BMS protection to support safer charge and discharge operation in 24V cold-weather RV, marine and low-temperature energy storage applications. It supports 50A continuous discharge, 100A peak discharge, IP65 protection, charging from -20°C~+55°C and discharging from -20~+60°C. It supports 2S4P configuration for flexible system design.

The LF2467N-BJ is designed with smart BMS protection to support safer charge and discharge operation in 24V cold-weather RV, marine and low-temperature energy storage applications. It supports 50A continuous discharge, 100A peak discharge, IP65 protection, charging from -20°C~+55°C and discharging from -20~+60°C. It supports 2S4P configuration for flexible system design.

Hysincere deep cycle battery life technology visual for long-lasting rechargeable battery performance

LF2467N-BJ ≥4000 Cycle Life Deep-Cycle LiFePO4 Battery

The LF2467N-BJ is built for long service life with ≥4000 cycle life, supporting stable rechargeable battery performance for B2B power applications. With 1715Wh rated energy, 50A continuous discharge and 5-year warranty support, it is suitable for reliable long-term use in 24V cold-weather RV, marine and low-temperature energy storage applications.

The LF2467N-BJ is built for long service life with ≥4000 cycle life, supporting stable rechargeable battery performance for B2B power applications. With 1715Wh rated energy, 50A continuous discharge and 5-year warranty support, it is suitable for reliable long-term use in 24V cold-weather RV, marine and low-temperature energy storage applications.

Technical Specifications

LF2467N-BJ Product Parameters

Main Parameters
ModelLF2467N-BJNominal Voltage25.6V
Maximum Charge Voltage29.2VDischarge Cut-off Voltage20V
Nominal Capacity67AhRated Energy1715Wh
Electrical Performance
Maximum Charge Current50AMaximum Continuous Discharge Current50A
Maximum Peak Discharge Current (5S)100AMaximum Series & Parallel2S4P
Temperature & Protection
Charge Temperature-20°C~+55°CDischarge Temperature-20~+60°C
IP Rating of EnclosureIP65Protection LevelIP65
Physical & Installation
TerminalsM8Dimension332*172*220mm
Weight12.4kg
Lifecycle & Compliance
Cycle Life≥4000LCD ScreenNO
CertificationN/A
Download Datasheet PDF

FAQ

What applications is the LF2463N-BJ battery suitable for?

The LF2463N-BJ is suitable for 24V/36V cold-weather energy storage systems. It is designed as a automatic self-heating when charging under 0°C with 25.6V nominal voltage, 63Ah capacity and 1612.8Wh rated energy.

Can the LF2463N-BJ charge in cold weather?

Yes. The LF2463N-BJ belongs to the Self-heating Series and is designed to automatically self-heat when charging under 0°C. Its specified charge temperature range is -20°C~+55°C, and discharge temperature range is -20~+60°C.

What are the charging and discharge specifications of the LF2463N-BJ?

The LF2463N-BJ uses 25.6V nominal voltage, 29.2V maximum charge voltage and 20V discharge cut-off voltage. It supports model-specific maximum charge current, model-specific maximum continuous discharge current and model-specific maximum peak discharge current.

Can the LF2463N-BJ be connected in series or parallel?

The catalog lists model-specific: 2S4P or 1S4P connection support for the LF2463N-BJ or its series. For safe system design, series/parallel wiring, charging equipment, fusing and communication settings should be confirmed before installation.

What temperature range, cycle life and warranty does the LF2463N-BJ provide?

The LF2463N-BJ is specified for charging within -20°C~+55°C and discharging within -20~+60°C. The catalog cycle life is ≥4000, and the series is listed with 5 years warranty support. Actual service life depends on depth of discharge, load profile, charging method and operating environment.
