Product Features

Stable Power Output

Delivers 34.56kWh for stable battery system operation in the Sodium Ion Energy Storage Battery Series.

Smart BMS Protection

Supports safer charge and discharge operation for OEM, ODM and project-based battery applications.

Long Cycle Life

Designed for long service life with catalog cycle life ≥3800.

Wide Temperature Operation

Supports charging from the catalog charge temperature range and discharging from the catalog discharge temperature range.

Hysincere Sodium Ion Energy Storage Battery Series application scenario for residential energy storage systems

SIB-HV35 576V 60Ah 34.56kWh Sodium Battery

The Hysincere SIB-HV35 is a 576V 60Ah 34.56kWh sodium battery in the Sodium Ion Energy Storage Battery Series, designed for reliable B2B power applications and customizable battery system integration.

The Hysincere SIB-HV35 is a 576V 60Ah 34.56kWh sodium battery in the Sodium Ion Energy Storage Battery Series, designed for reliable B2B power applications and customizable battery system integration.

Hysincere battery smart BMS protection technology for LiFePO4 and energy storage battery systems

SIB-HV35 Battery Management and Electrical Performance

The SIB-HV35 supports stable charge and discharge performance with catalog parameters including maximum charge voltage available on request, discharge cut-off voltage available on request, maximum charge current available on request, continuous discharge current available on request and peak discharge current available on request.

The SIB-HV35 supports stable charge and discharge performance with catalog parameters including maximum charge voltage available on request, discharge cut-off voltage available on request, maximum charge current available on request, continuous discharge current available on request and peak discharge current available on request.

Hysincere deep cycle battery life technology visual for long-lasting rechargeable battery performance

SIB-HV35 Long-Life Battery Solution

The SIB-HV35 is designed for dependable long-term operation with catalog cycle life ≥3800, charge temperature available on request, discharge temperature available on request, dimension 530*610*2100mm and weight 460kg.

The SIB-HV35 is designed for dependable long-term operation with catalog cycle life ≥3800, charge temperature available on request, discharge temperature available on request, dimension 530*610*2100mm and weight 460kg.

Technical Specifications

SIB-HV35 Product Parameters

Main Parameters
ModelSIB-HV35Cell ChemistrySodium lon
Nominal Voltage576VNominal Capacity60Ah
Rated Energy34.56kWhModule Energy(kWh)4.32
Module Nominal Voltage(V)72Module Capacity(Ah)60
Battery Module NumberSIB-HV35Battery Module Qty In Series(Optional)8
System Nominal Voltage(V)576System Operating Voltage(V)384-758.4
System Energy(kWh)34.56System Usable Energy(kWh)32.83
Rated DC Power34.56
Electrical Performance
Recommended Current30Nominal Current60
Peak Discharge Current120
Temperature & Protection
Working Temperature(℃)Charge: -10~55/Discharge:-30~55Status IndicatorYellow: Battery High Voltage Power On Red:Battery System Alarm
Communication PortCAN2.0/ RS485Humidity5%~85%RH
Altitude2000mIP Rating of EnclosureIP20
Storage Temperature(℃)0~35
Physical & Installation
Dimension530*610*2100mmWeight360/410/460
Installation LocationRack Mounting
Lifecycle & Compliance
Recommended Depth of Discharge90%Cycle Life25 2℃,0.5C/0.5C,EOL70% 3800
CertificationUN38.3Warranty10 years

FAQ

What is the SIB-HV35 and where is it used?

The SIB-HV35 is intended for stationary sodium-ion energy storage systems. Its listed core specifications are 576V nominal voltage, 60Ah nominal capacity, 34.56kWh rated energy. Final compatibility must be confirmed against the equipment voltage, load and mechanical space.

How should the SIB-HV35 be charged?

Use a charger whose chemistry, voltage and current settings match the SIB-HV35. Charger profile, connector polarity and BMS settings should be verified before use.

What discharge performance does the SIB-HV35 provide?

Discharge capability must be matched to the equipment's continuous and startup loads. The listed values are cycle life ≥3800. Cable gauge, fusing and protection settings must be sized for the complete system.

What are the size, weight and temperature limits of the SIB-HV35?

For the SIB-HV35, the listed physical and environmental specifications are dimensions 530*610*2100mm, weight 460kg. Connector, wire and enclosure options can change final dimensions and weight.

Can the SIB-HV35 be customized for an OEM project?

Hysincere can review the SIB-HV35 for OEM/ODM integration, including connector, wire, enclosure, BMS and labeling requirements. Product-specific notes: listed communication: CAN2.0 / RS485. Provide the device voltage, normal and peak current, installation space, operating temperature and required certifications for engineering confirmation.
