Product Features

LF12100M-B 12.8V 100Ah Bluetooth Power

Delivers 1280Wh rated energy for RV, marine, outdoor power and smart app monitoring applications.

Smart APP Battery Monitoring

Cellphone connected battery design supports convenient smart app monitoring for battery status and system operation.

Smart BMS Protection

Supports safer charge and discharge operation with intelligent battery management. Supports 100A continuous discharge and 200A peak discharge for demanding loads.

Maximum 4S4P Connection

Supports flexible system configuration for RV, marine, solar backup and lead-acid replacement power systems.

Hysincere Bluetooth Connection Series LiFePO4 battery application scenario with smart app monitoring

LF12100M-B 12.8V 100Ah LiFePO4 Battery for RV, Marine and Solar Power with Bluetooth App

The LF12100M-B is a 12.8V 100Ah Bluetooth LiFePO4 Battery from the Hysincere Bluetooth Connection Series, designed for RV, marine, solar and outdoor energy systems with Bluetooth smart app monitoring. It delivers 1280Wh rated energy with 100A continuous discharge performance. It also supports Bluetooth smart app monitoring.

The LF12100M-B is a 12.8V 100Ah Bluetooth LiFePO4 Battery from the Hysincere Bluetooth Connection Series, designed for RV, marine, solar and outdoor energy systems with Bluetooth smart app monitoring. It delivers 1280Wh rated energy with 100A continuous discharge performance. It also supports Bluetooth smart app monitoring.

Hysincere battery smart BMS protection technology for LiFePO4 and energy storage battery systems

LF12100M-B Smart BMS Protection for 100A Continuous Discharge

The LF12100M-B is designed with smart BMS protection to support safer charge and discharge operation in RV, marine, solar and outdoor energy systems with Bluetooth smart app monitoring. It supports 100A continuous discharge, 200A peak discharge, IP67 protection, charging from 0~+55°C and discharging from -20~+60°C. It supports 4S4P configuration for flexible system design.

The LF12100M-B is designed with smart BMS protection to support safer charge and discharge operation in RV, marine, solar and outdoor energy systems with Bluetooth smart app monitoring. It supports 100A continuous discharge, 200A peak discharge, IP67 protection, charging from 0~+55°C and discharging from -20~+60°C. It supports 4S4P configuration for flexible system design.

Hysincere deep cycle battery life technology visual for long-lasting rechargeable battery performance

LF12100M-B ≥4000 Cycle Life Deep-Cycle LiFePO4 Battery

The LF12100M-B is built for long service life with ≥4000 cycle life, supporting stable rechargeable battery performance for B2B power applications. With 1280Wh rated energy, 100A continuous discharge and 5-year warranty support, it is suitable for reliable long-term use in RV, marine, solar and outdoor energy systems with Bluetooth smart app monitoring.

The LF12100M-B is built for long service life with ≥4000 cycle life, supporting stable rechargeable battery performance for B2B power applications. With 1280Wh rated energy, 100A continuous discharge and 5-year warranty support, it is suitable for reliable long-term use in RV, marine, solar and outdoor energy systems with Bluetooth smart app monitoring.

Technical Specifications

LF12100M-B Product Parameters

Main Parameters
ModelLF12100M-BNominal Voltage12.8V
Maximum Charge Voltage14.6VDischarge Cut-off Voltage10V
Nominal Capacity100AhRated Energy1280Wh
Electrical Performance
Maximum Charge Current100AMaximum Continuous Discharge Current100A
Maximum Peak Discharge Current (5S)200AMaximum Series & Parallel4S4P
Temperature & Protection
Charge Temperature0~+55°CDischarge Temperature-20~+60°C
IP Rating of EnclosureIP67Protection LevelIP67
Physical & Installation
TerminalsM8Dimension332*172*220mm
Weight9.46kg
Lifecycle & Compliance
Cycle Life≥4000LCD ScreenNO
Certification(EU) 2023/1542 CE MSDS UN38.3
Download Datasheet PDF

FAQ

What applications is the LF12100M-B battery suitable for?

The LF12100M-B is suitable for RV, marine, off-grid and solar storage systems needing mobile monitoring. It is designed as a Bluetooth connection with smart app monitoring with 12.8V nominal voltage, 100Ah capacity and 1280Wh rated energy.

Does the LF12100M-B support Bluetooth monitoring?

Yes. The LF12100M-B belongs to the Bluetooth Connection Series and is designed for smart app monitoring, allowing users to check battery status more conveniently from a mobile device when the final system is configured correctly.

What are the charging and discharge specifications of the LF12100M-B?

The LF12100M-B uses 12.8V nominal voltage, 14.6V maximum charge voltage and 10V discharge cut-off voltage. It supports 100A maximum charge current, 100A maximum continuous discharge current and 200A maximum peak discharge current.

Can the LF12100M-B be connected in series or parallel?

The catalog lists 4S4P connection support for the LF12100M-B or its series. For safe system design, series/parallel wiring, charging equipment, fusing and communication settings should be confirmed before installation.

What temperature range, cycle life and warranty does the LF12100M-B provide?

The LF12100M-B is specified for charging within 0~+55°C and discharging within -20~+60°C. The catalog cycle life is ≥4000, and the series is listed with 5 years warranty support. Actual service life depends on depth of discharge, load profile, charging method and operating environment.
